Description

* Tilting pan, manual tilting

* Perfect 700 series, 1 module

* Device body is 18/8 Cr-Ni stainless steel stone sheet, chassis is 2mm aluminized sheet,

* The cover is made of double-walled stainless steel sheet, specially shaped for strength,

* Homogeneous heat distribution and preservation thanks to the compound pan base (3 mm stainless steel and 9 mm DKP material combined with a special method),

* The tilting mechanism can be easily turned without requiring force with its special mechanism and the tilting angle is 85 degrees,

* Faucet mounted to fill the pan with water for cleaning or use,

* Multi-stage thermostat with temperature adjustment between 50-300 C,

* It can work with LPG, NG and derivatives of these gases (G31, G25, G25.1, G27, G2.350) and can be converted without requiring any modification,

* Gas ​​valve; with pilot flame and thermocouple, with a structure that will automatically cut off the gas in case the flame goes out (safety valve),

* Gas ​​burner is in the form of a stainless steel pipe, and can work with all gases,

* Automatic ignition button,

* Safety system that automatically cuts off the power in case of any malfunction in the pan (limit thermostat),

* Switch mechanism that automatically cuts off gas flow when the roof is tilted,

* Adjustable feet made of stainless steel pipe.

TECHNICAL SPECIFICATIONS

Total Power	13	kW
Gas Inlet	3/4	inch
Consumption	11180	Kcal/h
Device Capacity	60	Lt
Cooking Surface Depth	435	mm
Cooking Surface Width	710	mm
Cooking Surface Height	200	mm
Pallet + Box Dimensions	822x772x1006	WxDxH
