Bakery Convection Oven 10 Trays Mechanical Control – Venix SG10M0G0
The SG10M0G0 is the mechanical ten-tray bakery oven in the Venix San Giorgio line: knobs and a timer instead of a screen, with steam injection. Where staff turnover is high or a site is far from service cover, a mechanical oven has fewer parts that can fail and fewer things to train on.
فرن حمل حراري بتحكم ميكانيكي من Venix طراز SG10M0G0 — 10 صواني 600×400 مم، خط San Giorgio، صناعة إيطالية. توريد وتركيب وصيانة من EKT في الدوحة.
- Description
- Additional information
- Explore The Features
- Reviews (0)
Description
Overview
The SG10M0G0 is the mechanical ten-tray bakery oven in the Venix San Giorgio line: knobs and a timer instead of a screen, with steam injection. Where staff turnover is high or a site is far from service cover, a mechanical oven has fewer parts that can fail and fewer things to train on.
Key features
- Mechanical controls — no display, no firmware, minimal training.
- Ten levels for 600 x 400 mm bakery trays or GN 1/1 gastronorm.
- Steam injection for crust development on bread and viennoiserie.
- Simpler to diagnose and repair on site than an electronic oven.
Technical specification
| Model / Ref | SG10M0G0 |
|---|---|
| Product line | Venix San Giorgio |
| Tray capacity | 10 trays 600×400 mm / GN 1/1 |
| Control | Mechanical |
| Origin | Italy |
Full electrical, water and dimensional data for this model is available on request — contact us and we will send the manufacturer technical sheet before you commit to an order.
Before you order
- ⚠ Do not confuse this model with the Venix SQ10M0G0 from the Squero line. The codes differ by one letter, both are ten-tray mechanical ovens, but the body, chamber and dimensions are different. Check the rating plate before ordering spare parts.
Installation notes
Qatar three-phase supply is nominally 415 V. Confirm the breaker rating and the water connection against the manufacturer technical sheet before ordering. A water softener is strongly recommended on Qatar mains to protect the steam injection system from scale. Allow clearance for the door swing and for service access at the rear.
Why Venix
Venix SRL builds its ovens in Castelminio di Resana near Venice. The Torcello, Campiello, Squero, San Giorgio and Sprìz lines are structured so an operator can move up in tray count or control level without changing brand, training or spare parts channel.
Supply and service in Qatar
Supplied, delivered, installed and commissioned by EKT from our premises in Doha. Our technicians handle warranty work and routine maintenance, and we stock Venix spare parts locally.
فرن حمل حراري بتحكم ميكانيكي من Venix طراز SG10M0G0 — 10 صواني 600×400 مم، خط San Giorgio، صناعة إيطالية. توريد وتركيب وصيانة من EKT في الدوحة.
Additional information
| Weight | 134 kg |
|---|---|
| Dimensions | 102,1 × 79,2 × 127,7 cm |
| Brand | Venix |
| Model / Ref | SG10M0G0 |
| Product Line | Venix San Giorgio |
| Tray Capacity | 10 trays 600×400 mm / GN 1/1 |
| Control | Mechanical |
| Country of Origin | Italy |
| Technology | ELECTRIC |
| Tray capacity | 10 600X400 – GN 1/1 |
| Distance between tray | 80 mm |
| Frequency (Hz) | 50/60 |
| Voltage | 380-415V 3N~/220-240V 3~ |
| Power (kW) | 16,1 |
| Oven size (WxDxH mm) | 792 x 1021 x 1277 |
| Max cooking temperature | 260°C |
| Oven weight (kg) | 134 |
| Blast chiller | ASP05 |
| Blast chiller stacking kit | SK16 |
